DZ-S50


Easier visual dermal observation

A pocket-size compact body with a large-diameter lens equipped with high-brightness LED. You can switch between polarised and non-polarised with one touch. You can more easily perform magnified observation of the lesion.

Man in a white coat shows the DZ-S50 in his breast pocket

Basic information


Product name

Dermoscope / DZ-S50


Accessories

AC adapter for charging, User's Guide


MDUFA No.

MD6119549


Device information

Dermoscope DZ-S50
• Regulation Number: 21 CFR § 880.6350
• Abbreviated 510(k)


Included

 The dermatology scope (DZ-S50) and the charging cable (AD-M50300A)


Detailed function


Large-diameter lens that allows you to see the details clearly

Features a large diameter 40.5mm (1.6") lens with a wide field of vision and low distortion. Since it is easy to focus, users can observe lesions without putting their face right next to the affected area or making fine position adjustments. The lens magnification is 6x.

Doctor examines person with the DZ-S50

Easy-to-use shape and design

The grip fits comfortably in the hand, and power and polarisation switching buttons are located where the user's fingers are positioned when holding it. At around 125 g, the device is lightweight, and thanks to the symmetrical shape, it can be used with both the left and right hand.


Power down by itself / Auto power off

The power supply unit switches off automatically approximately 3 minutes after it is switched on. This prevents the device being left unattended and reduces concerns about suddenly running out of battery power.


Bright and easy to see, high-luminance LED light

The LED light has an illumination intensity of 30,000 lux, allowing users to see lesions clearly in sharp detail and assisting accurate observation of colour. It is energy-efficient and provides approximately 120 minutes of continuous use on a single charge. This reduces concern about keeping patients waiting during recharge.

A person holds the DZ-S50 in their hand and small LED lights can be seen on the back.

Polarised, non-polarised mode switching with one touch

The LED light can be charged from polarised to non-polarised mode with a single switch. Polarised mode works best for observing pigment distribution beneath the skin's surface, while non-polarised mode is good for observing the condition of the skin's surface.

Two close-ups of a skin image, one polarised and one non-polarised

Optional accessories


Conversion lens
DSL-50M

An easy-to-fit conventional lens is available and can increase lens magnification from 6x to 9x. This is useful for observing minute lesions such as scabbles.

Conventional lens that is easy to attach with a magnet

Main specifications


Model DZ-S50
Lens magnification 6x/9x (with optional conversion lens attached)
Focal distance f=50 mm/f=31.25 mm (with conversion lens attached)
Maximum effective diameter 40.5 mm (1.6 inch)
No. of LED lights Polarised (6), non-polarised (3)
Power supply Lithium-ion battery (built-in)
Power supply Approx. 120 minutes (with continuously switched-on LED lights)
Size 67.5 × 140.2 × 23.1 mm (2.7" × 5.5" × 0.9") (W × H × D)
Weight Approx. 125 g, approx. 145 g (with optional conversion lens)
Accessories AC adapter for charging (AD-M50500A), User's Guide (with warranty card), Insertion document
