・Color Touch Screen ・Tri-Sensor 88-Note Scaled Hammer Action Keyboard ・Acoustic and Intelligent Resonator

PX-360M
PX-360M
PX-360M
PX-360M

Features

5.3" Color Touch Interface

Sound Technology

Unprecedented Natural Reproduction of the Rich Expressive Power and Resonance of an Acoustic Piano

Multi-dimensional Morphing AiR Sound Source

The characteristics of CASIO’s newly developed Multi-dimensional Morphing AiR* Sound Source reflect thorough attention to detail in expressing the rich, resonating tones inherent to the piano. The capacity of the installed memory has been expanded to achieve a longer sampling duration and enhanced waveform data quality. The temporal changes in tone that create sound you would expect only from a piano, beginning with the initial sound and leading into a beautiful extension until the sound eventually vanishes, are reproduced naturally.

*AiR = Acoustic and Intelligent Resonator

Keyboard System

Natural Playing Feel Approaching That of a Grand Piano Firm Touch That Converts the Player’s Thoughts into Sound

Tri-sensor Scaled Hammer Action Keyboard II, with a grand piano's unique sounding timing

The difference between the sound structures of a grand piano and a digital piano appears as a difference in timing, from the moment the instrument is played until the sound is audible. The new Tri-sensor Scaled Hammer Action Keyboard II responds by incorporating a system with three sensors that detect touches of the keys sequentially.

Simulated ebony and ivory keys with optimal fingertip fit for playing ease

The Simulated ebony and ivory keys offers the luxurious feel and texture as well as the smooth touch of a grand piano keyboard. The minutely detailed crimp surface finish inhibits finger slippage due to sweat and gives the sensation of a perfect fingertip fit, even when playing for extended periods.

Versatile features

Audio Recording(44.1 kHz WAV Format / up to approximately 74 min. per song)

550 tones including stereo-sampled grand piano tones

200 rhythms including ethnic rhythms and patterns for piano play

Rhythm Editor (10 user rhythms)

Registration (96 setups)

Music Preset feature including chord progressions for one-touch access to setups for a wide range of music styles (305 presets and 50 user areas)

Digital effects: reverb (17 types), chorus (16 types), delay (6 types), brilliance, DSP (preset for some tones)

Pitch Bend Wheel

Tone Select buttons for instant access

MIDI Recorder: 17 tracks x 100 songs, approximately 50,000 notes per song

USB TO DEVICE

LINE IN / OUT jacks (L/MONO, R for each)

Auto Power Off

Specifications

Keyboard
88-key, Tri-sensor Scaled Hammer Action Keyboard II, Simulated ebony and ivory keys
Number of Keys
88
Touch Response
3 sensitivity levels, Off
Sound Source
AiR Sound Source: String Resonance, Damper Resonance, Damper Noise, Hammer Response, Key Off Simulator
Maximum Polyphony
128
Number of Tones
550 built-in tones: 28 Grand Piano tones, 67 Elec Piano tones, 38 Organ tones, 40 Guiter tones, 22 Bass tones, 45 Strings tones, 27 Brass tones, 25 Read tones, 84 Synth tones, 38 Ethnic tones, 128 GM tones, 18 Drum sets
Number of Rhythms/Patterns
200 built-in rhythms, 10 user rhythms
Automatic Accompaniment
・Modes: CASIO Chord, Fingered 1, Fingered 2 (6th off), Fingered 3 (on bass), Full Range Chord ・Controllers: Start/Stop, Intro, Normal/Fill-in, Variation/Fill-in, Synchro/Ending
Demonstration Songs
6 (Demonstration-only Songs), Song Expansion (User Songs): 100 songs (max.) Up to approximately 700 KB/song
Recorder
[MIDI] 17 tracks (1 system track + 16 multi tracks), 100 songs, Punch-in/Punch-out recording, approximately 50,000 notes maximum per song (total for all song tracks) [Audio Recording] Max. 100 songs, approximately 74 min/song (44.1 kHz WAV format)
Pedal
・Included: SP-3 (terminal x 2) ・Optional: SP-33 (damper, soft, sostenuto) * damper = half-pedal operation
Speaker
12 cm x 2, 5 cm x 2 (4 speakers)
Amplifiers
8W+8W
Power Supply
AC adaptor: AD-A12150LW
Dimensions
1,322 x 293 x 139mm (w/o music stand), 1,322 x 293 x 765mm (with optional CS-67PBK/67PWE stand) * Excluding music stand, and other projections
Weight
11.9kg (main unit only), 21.9kg (with optionally available CS-67PBK/67PWE stand)
Color
Black
Included Accessories
Pedal (SP-3), AC Adaptor (AD-A12150LW), Music Stand, Dust Cover

Effects
Reverb (17 types), Chorus (16 types), Delay (6 types), Brilliance (-3 ~ 0 ~ 3), DSP (preset for some tones)
Layer/Split
Yes
Octave Shift
±2 octaves
Transpose
2 octaves (-12 semitones ~ 0 ~ +12 semitones)
Tuning Control
A4 = 415.5 Hz ~ 440.0 Hz ~ 465.9 Hz
Scales
Temperaments (preset scale): 17 types
Arpeggiator
Music Preset (including chord progressions): 305 presets + 50 user areas
Registration
96 sets (4 areas × 24 banks)
One Touch Presets
200 sets
Auto Harmonize
12 types
Metronome
0 to 9 beats; tempo range: 20 to 255, Tap tempo
LCD
5.3-inch touch panel (5.0-inch 528 x 320-dot TFT Color LCD)
Pitch Bend Wheel
00 to 24 semitones

Duet Mode
Yes
Others
・Dedicated piano tone buttons ・Operation Lock

LINE IN
2 (L / MONO, R), Standard jack
LINE OUT
2 (L / MONO, R), Standard jack
USB port
Type A, Type B
PEDAL
Pedals x 2 (Damper, Assignable)
Connector for 3-pedal unit
Yes
PHONES/OUTPUT
Phones x 2 (Stereo mini jack)

MIDI
GM Compatibility: Level1 Terminals: MIDI IN, OUT / THRU
