PX-870BK

My GShock

・AiR Sound Source ・19 Tones ・20W+20W

PX-870BK
PX-870BK
PX-870BK

Features

Sound Technology

Unprecedented Natural Reproduction of the Rich Expressive Power and Resonance of an Acoustic Piano

Multi-dimensional Morphing AiR Sound Source

The characteristics of CASIO’s newly developed Multi-dimensional Morphing AiR* Sound Source reflect thorough attention to detail in expressing the rich, resonating tones inherent to the piano. The capacity of the installed memory has been expanded to achieve a longer sampling duration and enhanced waveform data quality. The temporal changes in tone that create sound you would expect only from a piano, beginning with the initial sound and leading into a beautiful extension until the sound eventually vanishes, are reproduced naturally.

*AiR = Acoustic and Intelligent Resonator

Sound Projection

A newly developed sound system projects sound upward and downward like a grand piano. The sound is not confined inside the instrument, but passes out naturally through the speakers to realize a deep listening sensation like that produced by a grand piano.

Keyboard System

Natural Playing Feel Approaching That of a Grand Piano Firm Touch That Converts the Player’s Thoughts into Sound

Tri-sensor Scaled Hammer Action Keyboard II, with a grand piano’s unique sounding timing

The difference between the sound structures of a grand piano and a digital piano appears as a difference in timing, from the moment the instrument is played until the sound is audible. The new Tri-sensor Scaled Hammer Action Keyboard II responds by incorporating a system with three sensors that detect touches of the keys sequentially.

Simulated ebony and ivory keys with optimal fingertip fit for playing ease

The Simulated ebony and ivory keys offers the luxurious feel and texture as well as the smooth touch of a grand piano keyboard. The minutely detailed crimp surface finish inhibits finger slippage due to sweat and gives the sensation of a perfect fingertip fit, even when playing for extended periods.

Lid Simulator reproducing the sound effects resulting from an open lid

The sound volume and quality change when the lid on a grand piano is raised or lowered. The Lid Simulator reproduces the same acoustic effects for enhanced enjoyment with a digital piano. The acoustic effects of opening and closing the lid are simulated in fine detail. The piano sound you are seeking as you play is always available for your enjoyment by selecting the degree to which the lid is raised or lowered.

An unprecedented evolution of the digital piano

String Resonance resonator achieving deep, rich resonance with 88 keys

The sound produced by an acoustic piano is not only the sound associated with the keys that are struck. Other strings with frequencies closely associated with those producing the sounds resonate as well, adding their sound to give the music a uniquely rich resonance. In ordinary digital pianos, this string resonance effect is reproduced virtually with strings. The Multi-dimensional Morphing AiR sound source takes a different approach, however, by adopting a “string resonance” system incorporating a stereo resonance simulator for all 88 keys. The resonance of the 88 keys is reproduced completely and naturally. The resonance realized by playing a single tone is differentiated from that realized by playing a chord to reproduce the resulting variations in resonance in a natural manner. This even enables players to achieve varying resonances, controlling them at will by the strength of their touch, and thus to realize performances with the unique expressiveness of an acoustic piano.

Key Off Simulator reproducing tonal variations resulting from finger release

The lengths of the reverberations and expressions a piano produces vary depending on the speed at which players release their fingers after touching the keys. The new keyboard system incorporates a Key Off Simulator that reproduces these nuances resulting from key release naturally. Authentic reverberations that feel just like those of a grand piano are expressed as a result.

Damper Resonance* achieving a more naturally beautiful resonance than a pedal

The deep, beautiful resonance resulting from the use of a damper pedal is also reproduced naturally by a stereo resonance simulator installed on all 88 keys, an approach that differs from conventional simulated reproduction employing effect processing. The attention to detail goes so far as to simulate the resonance created by the lifting of the dampers themselves when the pedal is pressed. A continuously variable system has been adopted for the damper pedal, moreover, reproducing even the subtle changes in reverberation that occur in response to the delicate pressure exerted by partial pedal operation. This enables players to employ pedal operation to achieve gracefully expressive performances.

*4 adjustment levels

Hall Simulator

The Hall Simulator function simulates the differing acoustic characteristics of world-famous concert halls, from pure reverberation with outstanding tonal transparency to free-spirited, dazzling reverberation. An advanced equalizing system assures the pianist’s full enjoyment of vital piano sound.

Concert Play

High-quality audio data recordings of 10 live orchestra performances are installed. Pianists can play along with the recordings and enjoy the feeling of participating in a magnificent performance.

Headphone Mode

Headphone Mode automatically creates a spacious sonic image while wearing headphones, recreating the feeling of playing an acoustic piano. With the experience of wearing headphones significantly enhanced, pianists can enjoy playing naturally and feeling the sound field of a traditional grand piano.

Volume Sync EQ

Volume Sync EQ is especially useful for quiet playing at home and other times when you want to keep the speaker volume low. This function balances the sound at low volumes by adjusting the sound quality in the low and high registers. The result is a constantly pleasant playing experience, no matter where the volume is set.

Versatile features

  • Audio Recording (44.1 kHz WAV Format / up to approximately 25 min. per song)
  • 19 high-quality tones including stereo-sampled grand piano tones
  • Digital Effects: Hall Simulator (4 types), Chorus (4 types), Brilliance, DSP (preset for some tones)
  • Connection to App (Chordana Play for Piano Special Site)
  • Lesson feature using 60 Music Library songs plus 10 user loaded songs
  • GRAND PIANO button, ELEC PIANO 1 button
  • MIDI Recorder: 2 tracks x 1 song, approximately 5,000 notes total
  • USB flash drive port
  • PHONES/OUTPUT: 2 (Stereo standard)
  • AUTO POWER OFF

Specifications

Keyboard
Tri-sensor Scaled Hammer Action Keyboard Ⅱ (Key Surface Finish: Simulated ebony and ivory keys)
Number of keys
88
Touch response
3 sensitivity levels, off
Audio source
Multi-dimensional Morphing AiR
Polyphony
256
Number of tones
19
Built-in songs
60
Demo songs
Song Expansion (User Songs): 10 songs (max.) Up to approximately 90 KB / song
Lessons feature
Part on/off (Part Sslect: Right hand, Left hand)
Record feature
[MIDI Recorder] 2 tracks, 1 song Approximately 5,000 notes total Real-time recording [Audio Recorder] 99 songs Approximaterly 25 min / song Real-time recording, playback (To USB flash drive, 44.1 kHz Stereo WAV format)
Pedal
3 built-in pedals (damper, soft, sostenuto) Half-Damper Pedal Operation: Yes (Seamless recognition)
Speaker
12 cm x 2, 4 cm x 2, 2-Way, 4-Speaker
Amp output
20 W + 20 W
Power supply
[AC Adaptor] AD-E24250LW (DC 24V)
Power consumption
20W
Dimensions
1,393 x 299 x 801 mm (w/o music stand)
Weight
34.3 kg
Color
Black
Accessories
AC adaptor (AD-E24250LW), Music stand

Acoustic Simulator
Hammer Response (4 levels) Key Off Simulator String Resonance (4 levels) Damper Resonance (4 levels) Damper Noise Key On Action Noise Key Off Action Noise Lid Simulator (4 levels)
Effects
Hall Simulator (4 types) Chorus (4 types) Brilliance (-3 ~ 0 ~ +3) DSP (Preset for some tones)
Layer/Split
Yes
Octave Shift
-2 octaves ~ 0 ~ +2 octaves
Transpose
-12 semitones ~ 0 ~ +12 semitones
Tuning Control
A4 = 415.5 Hz ~ 440.0 Hz ~ 465.9 Hz
Scales
Equal temperament + 16 variations
Metronome
0 to 9 beats; tempo range: 20 to 255

Sound Projection
Yes
Concert Play
10 songs, Playback Mode: LISTEN, LESSON, PLAY, Controller: START, STOP
Headphone mode
Yes
Duet Mode
Yes
Volume Sync EQ
Yes
Others
・Auto Power Off ・Slide-type keyboard cover

USB port
Type A, Type B
Connector for 3-pedal unit
Yes
PHONES/OUTPUT
2 (Stereo standard jack)

Connection to App
Yes (Chordana Play for Piano)
MIDI
Yes (Using the USB port)
Built-in Songs
  • Nocturne Op.9-2
  • Fantaisie-Impromptu Op.66
  • Étude Op.10-3 "Chanson de l'adieu"
  • Étude Op.10-5 "Black Keys"
  • Étude Op.10-12 "Revolutionary"
  • Étude Op.25-9 "Butterflies"
  • Prélude Op.28-7
  • Valse Op.64-1 "Petit Chien"
  • Valse Op.64-2
  • Moments Musicaux 3
  • Impromptu Op.90-2
  • Marche Militaire 1 (Duet)
  • Frühlingslied [Lieder Ohne Worte Heft 5]
  • Fröhlicher Landmann [Album für die Jugend]
  • Von fremden Ländern und Menschen [Kinderszenen]
  • Träumerei [Kinderszenen]
  • Tambourin
  • Menuet BWV Anh.114 [Clavierbüchlein der Anna Magdalena Bach]
  • Inventio 1 BWV 772
  • Inventio 8 BWV 779
  • Inventio 13 BWV 784
  • Praeludium 1 BWV 846 [Das Wohltemperierte Klavier 1]
  • Le Coucou
  • Gavotte
  • Sonatina Op.36-1 1st Mov.
  • Sonatine Op.20-1 1st Mov.
  • Sonate K.545 1st Mov.
  • Sonate K.331 3rd Mov. "Turkish March"
  • Rondo K.485
  • Für Elise
  • Marcia alla Turca
  • Sonate Op.13 "Pathëtique" 1st Mov.
  • Sonate Op.13 "Pathëtique" 2nd Mov.
  • Sonate Op.13 "Pathëtique" 3rd Mov.
  • Sonate Op.27-2 "Moonlight" 1st Mov.
  • Rhapsodie 2
  • Waltz Op.39-15 (Duet)
  • Liebesträume 3
  • Blumenlied
  • La Prière d'une Vierge
  • Csikos Post
  • Humoresque Op.101-7
  • Melodie [Lyrische Stücke Heft 2]
  • Sicilienne Op.78
  • Berceuse [Dolly] (Duet)
  • Arabesque 1
  • La Fille aux Cheveux de Lin [Préludes]
  • Passepied [Suite bergamasque]
  • Gymnopédie 1
  • Je Te Veux
  • Salut d'Amour
  • The Entertainer
  • Maple Leaf Rag
  • L'arabesque [25 Etüden Op.100]
  • La Styrienne [25 Etüden Op.100]
  • Ave Maria [25 Etüden Op.100]
  • Le retour [25 Etüden Op.100]
  • La chevaleresque [25 Etüden Op.100]
  • No.13 [Études de Mécanisme Op.849]
  • No.26 [Études de Mécanisme Op.849]
