MASTER OF G - LAND
MUDMASTER

GG-B100BA-1A

My GShock

This is a model from the G-Shock Mudmaster Series, designed for use in extreme environments scattered with rubble, dirt and debris. It was created in collaboration with the British Army. It is based on the GG-B100, which uses carbon materials to provide shock, dust and mud resistance while also featuring compass, altimeter/barometer, temperature measurement and pedometer functions. Under the supervision of the British Army, both the watch and its packaging feature camouflage patterns reminiscent of camo clothes. The army logo is depicted on the band ring and packaging, and the model has been given other finishing touches befitting such a collaboration, including metal for the band ring's material. This is a special collaboration model between the British Army, who participate in the toughest of missions, and G-Shock, which supports their activities with the most advanced watch features.

GG-B100BA-1A
GG-B100BA-1A
GG-B100BA-1A
GG-B100BA-1A
GG-B100BA-1A
GG-B100BA-1A
GG-B100BA-1A
GG-B100BA-1A
GG-B100BA-1A

Specifications

Price
MSRP RM1,999.00
Case size (L× W× H)
55.4 × 53.1 × 19.3 mm
Weight
97 g
Case and bezel material
Case / bezel material: Carbon / Resin
Band
Resin Band
Construction
Mud Resistant
Carbon Core Guard structure
Shock Resistant
Water resistance
200-meter water resistance
Power supply and battery life
Approx. battery life: 2 years on CR2025
Sensor feature
Step count using a 3-axis acceleration sensor: 0 to 999,999 step count display range Power Saving: Auto sensor sleep state entry after fixed period of non-activity
Altimeter Measuring range: -700 to 10,000 m (-2,300 to 32,800 ft.) Measuring unit: 1 m (5 ft.) Hand indication graph of altitude differential Manual memory measurements (up to 14 records, each including altitude, date, time) Auto log data (High/low altitudes, cumulative ascent and descent) Others: Relative altitude readings (±100 m /±1000 m), selectable measurement interval: 5 seconds or 2 minutes (1 second for first 3 minutes only) *Changeover between meters (m) and feet (ft)
Barometer Measuring range: 260 to 1,100 hPa (7.65 to 32.45 inHg) Measuring unit: 1 hPa (0.05 inHg) Hand indication of pressure differential (±10 hPa) Atmospheric pressure tendency graph (last 20 hours or last 56 hours) Barometric pressure tendency information alarm (beep and arrow indicates significant changes in pressure) The atmospheric pressure tendency graph can show the last 20 minutes or last 56 minutes of measurements. The hand indication of pressure differential shows values in units of ±1 hPa. *Changeover between hPa and inHg
Digital compass Measures and displays direction as one of 16 points Measuring range: 0 to 359° Measuring unit: 1° 60 seconds continuous measurement Hand indication of north Magnetic declination correction Direction calibration (2-point calibration, figure eight calibration, auto calibration)
Thermometer Measuring range: -10 to 60℃ (14 to 140℉) Measuring unit: 0.1℃ (0.2℉) *Changeover between Celsius (℃) and Fahrenheit (℉)

Smartphone Link feature
Mobile link (Wireless linking using Bluetooth®)
Apps
G-SHOCK Connected

Glass
Mineral Glass
Spherical Glass
Other
Neobrite

World time
World time 38 time zones (38 cities + coordinated universal time), daylight saving on/off, Home city/World time city swapping
Sunrise/sunset display
Sunrise, sunset time display Sunrise time and sunset time for specific date
Stopwatch
1/100-second stopwatch 00'00''00~59'59''99 (for the first 60 minutes) 1:00'00~23:59'59 (after 60 minutes) Measuring unit: 1/100 second (for the first 60 minutes) 1 second (after 60 minutes) Measuring modes: Elapsed time, split time, 1st-2nd place times
Timer
Countdown timer Measuring unit: 1 second Countdown range: 24 hours Countdown start time setting range: 1 second to 24 hours (1-minute increments and 1-hour increments)
Alarm/hourly time signal
5 daily alarms
Hourly time signal
Light
Double LED light LED light for the face (Auto LED light, Super illuminator, selectable illumination duration (1.5 seconds or 3 seconds), afterglow) LED backlight for the digital display (Auto LED light, Super illuminator, selectable illumination duration (1.5 seconds or 3 seconds), afterglow)
Light color
LED:White
Calendar
Full auto-calendar (to year 2099)
Mute feature
Button operation tone on/off
Accuracy
Accuracy: ±15 seconds per month (with no mobile link function)
Other features
12/24-hour format
Hand shift feature
Regular timekeeping: Analog: 3 hands (hour, minute (hand moves every 10 seconds), second) Digital: Hour, minute, second, am/pm, month, date, day

Features

Shock resistant button - A cleaner design that removes the button guard was achieved through improved case strength and the newly developed structure.

Carbon Core Guard structure

This new shock resistant structure protects modules with a carbon fiber reinforced resin case.

Mud resistant structure (dust and mud resistant)

Mud resistant  structure  (dust and mud resistant)

Highly airtight carbon case and filter protects against intrusion of mud.

Dual layered case back

Dual layered case back

Carbon fiber inserted bezel

Carbon fiber inserted bezel

A triple layered structure with a carbon fiber sheet inserted between fine resin.

カーボンファイバーインサートベゼル

Technology / Design

Quad sensor

Quad sensor

Super Illuminator (high brightness LED)

Super Illuminator  (high brightness LED)

Application

G-SHOCK Connected

G-SHOCK Connected FREE

Smartphone App

Main Functions

- Mission Log function
The altitude measured by the watch and the course obtained from a smartphone’s GPS are automatically recorded to an app. An altitude point can be manually acquired and plotted on the map.

- Location Indicator
Record your current location in an app. Display shows your recorded destination by the second hand, and the distance on the LCD.

- Calorie calculator
- Mode/display switching customization
- Automatic time adjustment*
- World Time for over 300 cities*
- Phone Finder

* Updating of internal data according to the latest time zone/ daylight saving time information

* App screens shown here may differ from actual screens,
since the app is currently under development.

Supported Phone Models (As of Jan 2019)

iOS: iOS 10 or later
Android: Android 6.0 or later

* Bluetooth installed smartphone only.

* Bluetooth® wordmark and logo are registered trademarks of Bluetooth SIG, Inc. and any use of these marks by Casio Computer Co., Ltd. is under license.
* Apple, Apple logo and iPhone are trademark of Apple Inc. registered in the United States and other countries. App Store is a service mark of Apple Inc.
* IOS is a trademark or registered trademark of Cisco Systems, Inc. registered in the U.S.
* Google Play and the Google Play logo are trademarks of Google LLC.
* All other company and product names are trademarks or registered trademarks of their respective owners.

*The color tone of the listed products may differ from the actual product in some cases.
